316h Kub Rolled Stainless Hlau Phaj
1.Standard: ASTM A240 / ASME SA240
2.Thickness: 0.1mm-200mm
3.Width: 800-3000 hli
4.Length: 1000-6000 hli
316h kub dov stainless hlau phajyog ib tug high-carbon version ntawm 316 thiab 316L cov ntaub ntawv. Cov pa roj carbon monoxide tuaj yeem txhim kho qhov ntsuas kub ntawm cov khoom siv, kev siv kub ntau yog 550 degree txog 850 degree. Cov ntsiab lus chromium hauvS31609feem ntau yog nyob nruab nrab ntawm 16-18%. Cr yog lub ntsiab alloying ntawm stainless hlau thiab muaj peev xwm tsim ib tug ntom chromium oxide txheej los muab corrosion kuj thiab oxidation kuj.
Stainless hlau 316H Kub Rolled (HR) Daim Ntawv Thov:
- Cov cua kub kub
- Cov khoom siv kho cua sov
- Cov txheej txheem tshuaj
- Petroleum Kev Lag Luam
- Kev Lag Luam Hluav Taws Xob thiab Hluav Taws Xob
- Thaum tshav kub kub Exchangers
ASME SA 240 SS 316H Phaj Specifications
| Txuj | ASTM A240 / ASME SA240 / ASTM A240 / ASTM A240 / ASME SA240 / ASTM A240 / ASTM A240 / ASME SA240 / ASTM A240 / ASTM A240 / ASME SA240 / ASTM A240 / ASTM A240 / ASME SA240 / ASTM A240 / ASTM A240 / ASME SA240 / ASTM A240 / ASME SA240 / ASTM A240 / ASTM A240 / ASTM A240 / ASME SA240 / ASME SA240 / ASTM A240 / ASME SA240 / ASTM A240 / ASME SA240 / ASTM A240 / ASME SA240 / ASTM A240 / ASME SA240 / ASTM A240 / ASME SA240) |
| Kev tsim khoom | Kub Rolled (HR) |
| Thickness | 0.6MM txog 80MM THICKNESS |
| Dav | 1250 MM / 1500 MM / 2000 MM / 04 Feet / 05 Feet thiab Kev Cai Txiav Dav raws li Kev Xav Tau |
| Ntev | 2400 MM / 2420 MM / 6000 MM / 08 Feet / 10 Feet / Coil Cut thiab Custom Cut Length as Per Requirement |
| Nto tiav | 2B, 2D, BA, MATT, MATT PVC, No.4, No.5, SB, HR, No.8, Daim iav, Hairline, Txhuam, Textured, Roj puag ntub Polished, Ob sab Polished muaj. |
| Txheej | PVC txheej Ib txwm / Laser, Zaj duab xis: 100 micrometer, Xim: dub / dawb. |
| ASTM A240 316H Stainless Hlau Phaj Lwm Yam Kev Ntsuas | NACE MR0175, Ultrasoung TEST, IGC TEST, Intergranular Corrrosion Test as per ASTM A262 Practice E, Charpy Impact Test, Macro, Grain Size, Hardness, thiab lwm yam. |
| Ntim | Loose / Carrate / Ntoo Pallet / Ntoo thawv-a / Plastic Cloth Wraps |
| Daim Ntawv Pov Thawj | Chaw tsim tshuaj paus Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Nyob rau hauv Lub Chaw Saib Xyuas Thib Peb Zoo li SGS, TUV, DNV, LLOYDS, ABS, Bureau of Indian Standards BIS Pom Zoo ETC |
1.4919 Stainless Hlau Mechanical Properties
| Yield zog | .2% Offset | psi (min.) | 30,000 |
| (MPa) | 205 | ||
| Qhov kawg Tensile | Lub zog | psi (min.) | 75,000 |
| (MPa) | 515 | ||
| Elongation | ua 2in. | % | 40 |
| Hardness | - | 95 Rockwell B | |
316H vs 316 316L stainless hlau
- Muaj peev xwm ua haujlwm kub kub: Vim nws cov ntsiab lus carbon siab, 316H muaj qhov ua kom sov zoo dua li 316 thiab 316L hauv qhov kub thiab txias. Yog li ntawd, 316H feem ntau yog siv nyob rau hauv high-temperature furnaces, cov khoom siv kho cua sov, burners thiab lwm yam teb.
- Intergranular corrosion kuj: Los ntawm kev tswj cov ntsiab lus carbon,AISI 316Htxhim kho intergranular corrosion kuj thiab txo qhov kev pheej hmoo ntawm intergranular corrosion.
- Lub zog thiab tensile zog: 316H muaj zog tensile ntau dua thiab ductility, tso cai rau nws ua tau zoo nyob rau hauv ib puag ncig kev nyuaj siab.
316H Kub Rolled Stainless Hlau Phaj txheej txheem
- Kev npaj raw khoom
- Smelting
- Nruam Casting
- Kub Rolling Processing
- Kev kho cua sov
- Kev kho saum npoo
- Kev sim
FAQ
Q: Tus nqi 316H Phaj yog dab tsi?
Q: Puas yog Hauv Tshuag?
Q: Puas muaj Kev Pabcuam Qauv?
Q: Yam tsawg kawg nkaus Order Quantity yog dab tsi?
Q: Lub sijhawm xa khoom ntev npaum li cas?
Q: Txoj kev them nyiaj twg tau txais kev txhawb nqa?
Q: Koj puas muab Factory Test Certificate?
Q: Koj puas txhawb nqa cov khoom lag luam?
Cim npe nrov: Kub dov stainless hlau phaj, 316h stainless hlau phaj, 316h phaj, 316h stainless hlau
